The Pro-Digi phantom is dedicated for acceptance and constancy tests of digital radiography equipment.

It can be used to measure:

  • collimation / beam alignment
  • position and size of the effective radiation field
  • dynamic range
  • spatial resolution
  • contrast resolution
  • homogeneity

Technical data (can be modified to customer specifications):

  • dimensions: 310 x 310 x 14 mm
  • 1 mm thick copper plate embedded in PMMA
  • 7-step copper wedge
  • 6 low contrast elements
  • free area for signal calibration
  • markings to determine the size and position of the effective radiation field
  • pattern for line pair resolution evaluation (from 0.6 to 5.0 LP/mm)
  • cone for perpendicular X-Ray beam control in the range of 0° ÷ 1.5°

Product features:

  • complies with:
    – IEC 61223-3-1
    – DIN 6868/58 and DIN 6868/13
  • CE certified
  • the manual provides detailed guidelines for carrying out each test, results assessment and registration
